Eltako RS485 bus actuator universal dimmer switch up to 800 W FUD14/800W

Universal dimmer switch, Power MOSFET up to 800 W. Automatic lamp detection. Only 0.3 watt standby loss. With adjustable minimum brightness or maximum brightness and dimming speed. With switching operation for light alarm clocks, children’s rooms and snooze function. Also with light scene control and constant light regulation. Operation only possible with the wireless antenna

Eltako RS485 bus actuator Staircase off-delay timer FTN14

Staircase off-delay timer, 1 NO contact not potential free 16 A/250 V AC, 230 V LED lamps up to 400 W, incandescent lamps up to 2000 watts, switch-off early warning and switchable pushbutton permanent light. Also for energy saving lamps ESL up to 200 Watt. Bidirectional. Only 0.2 watt standby loss. Operation only possible with

Eltako RS485 bus actuator heating/cooling relay FHK14

Heating/cooling relay, 1+1 NO contacts potential free 4 A/250 V AC, with DX technology. Bidirectional. Only 0.1 watt standby loss. Operation only possible with the wireless antenna module FAM14.

Eltako RS485 bus meter collector F3Z14D

Wireless meter concentrator for electricity, gas and water meters. For 3 S0 interfaces and/or 3 AFZ scanners, only 0.1 watt standby loss. Operation only possible with the wireless antenna module FAM14.

Eltako RS485 bus energy meter data gateway FSDG14

Wireless energy meter data gateway for meters equipped with an IEC 62056-21 IR interface. 2 channels. Only 0.4 watt standby loss. Operation only possible with the wireless antenna module FAM14.

Eltako RS485 Bus Weather Data Gateway FWG14MS for multisensor MS

Weather data gateway for multi sensor MS. Bidirectional. Only 0.3 watt standby loss. Operation only possible with the wireless antenna module FAM14.

Eltako RS485 bus actuator 4-channel impulse switch with integrated relay function for LED F4SR14-LED

4-channel impulse switch with integrated relay function, 1 NO contact per channel up to 8 A/250 V AC, 230 V LED lamps up to 400 W, incandescent lamps 1800 watts, potential free from the power supply, with DX technology. Bidirectional. Only 0.1 watt standby loss. Operation only possible with the wireless antenna module FAM14.

Eltako RS485 bus wireless antenna module FAM14

Wireless antenna module for the Eltako RS485 bus with exchangeable antenna. With enclosed power supply FSNT14-12V/12W. Bidirectional. Encrypted ­wireless. Only 0.8 watt stand­by loss. If required, a wireless antenna FA250 or FA200 can be connected.

Eltako RS485 bus multiple gateway FGW14

Multiple Gateway. Bidirectional. Only 0.5 watt standby loss. Operation only possible with the wireless antenna module FAM14.

Eltako DALI gateway FDG14

DALI gateway FDG14, bidirectional. Only 1 watt standby loss. Operation only possible with the wireless antenna module FAM14.
