Eltako RS485 bus display timer FSU14

Display timer with 8 channels for the Eltako RS485 bus. With “astro” function. Only 0.1 watt standby loss. Operation only possible with the wireless antenna module FAM14.

Eltako RS485 bus wireless three-phase energy meter DSZ14DRS-3x80A MID with display, MID approval

RS485 bus wireless three-phase energy meter. Maximum current 3 x 80 A. Standby loss 0.8 W at L1 and only 0.5 W at L2 and L3 each. Operation only possible with the wireless antenna module FAM14.

Eltako RS485 bus multifunction sensor relay FMSR14

Multifunction sensor relay with display and 5 channels (brightness, twilight, wind, rain and frost) for the Eltako RS485 bus. Only 0.1 watt standby loss. Operation only possible with the wireless antenna module FAM14.

Eltako RS485 bus 1 and 2 level wireless repeater FRP14

1 and 2 level wireless repeater with small antenna. Only 0.6 watt standby loss. If required, a wireless antenna FA250 can be connected. Operation only possible with the wireless antenna module FAM14.

Eltako RS485 bus wireless three-phase energy meter DSZ14WDRS-3x5A with settable CT ratio with display, MID approval

RS485 bus wireless three-phase energy meter with settable CT ratio and MID. Maximum current 3×5 A. Standby loss 0.8 W at L1 and only 0.5 W at L2 and L3 each. Operation only possible with the wireless antenna module FAM14.

Eltako RS485 bus actuator 4-channel heating/cooling relay F4HK14

Heating/cooling relay with 4 channels, 1 NO contact per channel 4 A/250 V AC, potential free from the power supply, with DX technology. Bidirectional. Only 0.1 watt standby loss. Operation only possible with the wireless antenna module FAM14.

Eltako RS485 bus wireless single-phase energy meter transmitter module 65 A FWZ14-65A

Wireless single-phase energy meter transmitter module, maximum current 65 A. Only 0.5 watt standby loss. Operation only possible with the wireless antenna module FAM14.

Eltako RS485 bus pushbutton gateway FTS14TG

Pushbutton gateway for FTS14 systems. Only 1.3 watt standby loss.

Eltako RS485 bus telegram duplicator FTD14

Telegram duplicator for the Eltako RS485 bus with exchangeable antenna. Only 0.5 watt standby loss. Operation only possible with the wireless antenna module FAM14.

Eltako RS485 bus pushbutton input module FTS14EM

Input module for the Eltako RS485 bus, 10 control inputs for universal ­control voltage. Only 0.1 watt standby loss.
