VL-707 STYLE, Control Panel with EnOcean-Interface, 7″ capacitive touchscreen

The VL-707 STYLE is a small control panel of the high-end SYTLE series with capacitive glass touch (Multi-Touch) and plenty of interfaces for automation projects:

3x Ethernet 10/100, 2x USB Host (2.0) and a combined, serial interface (RS-232/RS-422/RS-485), 1x SD card .

The EnOcean-Interface is based on the EnOcean USB-Stick, connected to the USB-Host port of the control panel.

Based on the glass touchscreen and the bright display, the customer can design and implement state-of-the-art user interfaces. To develop these, you have to use our software tool JMobile Studio (not included), which offers for exmaple the following features:

  • Full support of vector graphics (scaling, transparency, alpha-blending)
  • Data display: i.e. numerical, as text, bargraph, analog instruments
  • Functions like dada logger, trends, alarm-handler, time-triggered events (scheduler)
  • User management
  • E-Mail
  • RSS feeds
  • Numerous communication drivers, up to 4 can be used in a project at the same time
  • Online and offline simulation in JMobile Studio available
  • Extensive library of vector symbols and objects

This post is also available in: German Chinese (Simplified) French Italian Japanese

  • Product No. # 11823, VL-707 STYLE
  • Manufacturer DEUTA Controlshttp://www.deuta-controls.de
  • Category Gateway & Building Management Systems, Gateway: BACnet, Gateway: DALI, Gateway: GSM, Gateway: KNX, Gateway: Modbus, Gateway: Other, Gateway: RS232, Gateway: RS485, Gateway: TCP/ IP, Gateway: USB
  • Field Of Use HVAC, Industrial, Lighting
  • Frequency 868 MHz (ASK): Europe (and potentially others, e.g. China)
  • RX-EEP F6-03-01, F6-03-02, A5-07-01, A5-07-02, A5-07-03, A5-06-01, A5-06-02, A5-08-01, D2-05-02
  • Certification Certified 2.0
