Wireless Motion/Lux Sensor

[Mx-ML2] Motion and lux sensor

STM 350U – Batteryless and Wireless Temperature & Humidity Sensor Module

The extremely power saving RF transmitter module STM 350 of EnOcean is optimized for realization of wireless and maintenance free temperature and humidity sensors or room operating panels including set point dial and occupancy button using the EnOcean radio standard. It requires no external components and provides onboard a calibrated temperature and humidity sensor. Power

EPACU – EnOcean People Activity Counter (902 MHz)

The ceiling mounted sensor is detecting people motion activity in the sensing range underneath the sensor. The device is wireless and solar-powered, so no batteries are needed under typical light conditions and easiest to mount also in retrofitting.

EOSDU – Occupancy Sensor Sub Desk

The Sub-desk mounted Occupancy Sensor is detecting when a desk is occupied or vacant based on motion in the space underneath the desk. This device is wireless, and uses a passive infrared (PIR) sensor to detect such motion. The occupancy sensor transmits RF signals to control desk power supply or sends people counting information to

Keycard Stations

The PTM265KCAU Key Card Activated Switch is kinetic powered while the KSS Key Card Switch Station is battery powered and communicates wirelessly with Echoflex Controllers making it easy to add suite level setback control of heating, air conditioning, and lighting circuits, thus reducing energy consumption and operational costs. The Keycard stations are commonly used in

Active Circuit Transmitter and Repeater

The Echoflex Active Circuit Transmitter ERM-DA indicates when a electrical 120V to 277V circuit is active, transmitting an EnOcean standard occupancy profile telegram. The Active Circuit Transmitter (ERM-DA-LV) indicates when a 24V AC/DC electrical circuit is active by transmitting a standard occupancy profile telegram.

Signal Relay

Signal Relay for controlling HVAC or any miscellaneous electrical loads (24VAC/DC) with central command support for BEMS gateway control

Resonate Hand Held Switch

The single and dual Handheld switches are self-powered and communicate wirelessly to linked devices. Each paddle can be linked to different controllers to manage multiple circuits. The switch can serve as a straightforward control device, or be part of a complex multi-input strategy, supporting configurations from 3-way to 20-way switching.

Resonate Wave Switch

The single and dual resonate wave switches are self-powered and communicate wirelessly to linked devices. Each paddle can be linked to different controllers to manage multiple circuits. The switch can serve as a straightforward control device, or be part of a complex multi-input strategy, supporting configurations from 3-way to 20-way switching.

Wall Occupancy Sensor

The ROS wall-mounted sensor that uses passive infrared (PIR) technology to detect occupancy. It uses wireless technology to communicate with Echoflex controllers to efficiently manage lighting and increase energy savings. The ROS occupancy sensor is available in models for wide angle, corner mount and hallway or high-bay end of aisle applications.
