EnOcean Easyclickpro module JR, 4-channel, 2 HP, for 2 blinds/shutters

The EnOcean Easyclick JR module for 2 blinds/shutters receives its telegrams via the external Easyclick aerial module and uses its power sections to implement the configured functions and parameters. The Easyclick modules are linked to each other with modular plug-in cables. The Easyclick JR module is used to regulate blinds/shutters based on a range of functions and parameters configured at rotary switches. A function can be defined individually for each programmed transmitter. Standard function: UP/STOP/DOWN with slat adjust. Selected functions include e.g. UP/STOP/DOWN w/o slat adjust, slat adjust ON/OFF, safety function for blocking, UP/ DOWN lighting scenes, etc.

Necessary equipment:
Antenna: https://www.enocean-alliance.org/product/peha_easyclick-antenna_module/
Power supply: https://www.enocean-alliance.org/product/peha_easyclick-module-spv-2-te/

Technical data:
DRA device for mounting on 36 mm DIN rails (2 HP)
Own consumption: standby = approx 0.4 W operation = approx 21 mA / 0.51 W
4 relay outputs for two 230 Vac motor blinds/shutters (max 1 A)
Rotary switches for functions and parameters
LRN/CLR button
LED status display
Modular sockets
incl 30 cm connecting cable
Rating: IP 20
Approvals: CE, KEMA/KEUR

  • Product No. D 454 FU-JR 2REG (00377937)
  • Manufacturer Honeywell PEHAhttp://www.peha.de
  • Category Actuator / Relay Receiver, Receivers & Controllers
  • Frequency 868 MHz (ASK): Europe, China
  • RX-EEP A5-38-08, A5-11-03
  • Certification Certified Level 2
